U-profile magnet 15x15x4 mm
- Buy 5 for EUR 2.38 each and save 12%
- Buy 20 for EUR 2.06 each and save 24%
- Buy 40 for EUR 1.93 each and save 29%
- Buy 80 for EUR 1.80 each and save 34%
To request a quote please provide the information below. You can list a number of maximum 6 different desired number of pieces to be quoted.
When you have sent the form we will return with a quote typically within 48 hours.
Description
The Channel magnet measures 15x15x4 mm and has a strength of 5.5 kg.
The channel magnet is a neodymium magnet encased in a steel U-profile that can be mounted with a countersunk screw. The U-profile increases the strength of the magnet when it is in direct contact with an iron surface.
The strength of the channel magnet is measured in horizontal pull. In other words, how many kilograms it can withstand before loosening when attached to, for example, a ceiling beam. If the channel magnet is placed on a smooth vertical surface (e.g. a metal wall), you may find that it slides down before reaching its maximum load capacity.
Read more here: What does strength, holding power and load capacity mean?
NB. Please note that the channel magnet is not made from stainless steel and should only be used indoors.If you need screws for the magnets, they will work with the following:
- Slotted countersunk wood screw: DIN 97 (3.5 mm)
- Cross recessed countersunk flat head screws (machine screw): ISO 7046-2 M3 (3 mm)
- Hexalobular socket countersunk flat head screws (machine screw) ISO 14581 M3 (3 mm)
- Hexagon socket countersunk flat head screws (machine screw) ISO 10642 M3 (3 mm)
Specifications
| SKU | CHCSN-15-15-04 |
|---|---|
| Strength (kg) | 5.50 kg |
| Type | Channel magnet |
| Length (S1) | 15.00 mm |
| Width (S2) | 15.00 mm |
| Height (H) | 4.00 mm |
| Countersinking depth (t) | 2.48 mm |
| Countersink (d2) | 9.46 mm |
| Magnetisation | N38 |
| Material | Neodymium, Steel |
| BHmax (Maximum Energy Product) | 36-38 MGOe |
| Brmax (Residual Flux Density) | 12200-12600 gauss |
| Max operating temperature | 80 °C °C |
| Curie temperature | 310 °C °C |
| Coating | Nickel (Ni-Cu-Ni) |
| Delivery | Delivery: 3-6 days |
| Brand | Brisingi |
